Poly Butadiene Rubber (PBR)

Tejarat Sabz Mana is ready to supply Poly Butadiene Rubber with Best conditions.

IS a polymer formed from the polymerization process of the monomer 1,3 – Butadiene, has a high resistance to wear and is used especially in the manufacture of tires, also it is used as an additive to improve the mechanical strength of plastics such as polystyrene and acrylonitrile butadiene styrene (ABS).

* Raw Material

Typical Properties	Test Method	Unit	Value
CIS Content	ZEON R-130A	WT%	MIN 97
Raw Mooney Viscosity	ASTM D-1646	ML-4	41-49
Volatile Material	ASTM D-1416	WT%	MAX 0.5
Ash Content	ASTM D-1416	WT%	MAX 0.3

** Compound Properties

Typical Properties	Test Method	Unit	Value
Compound Mooney Viscosity	ASTM D-1646	ML-4	MAX 77
Tensile (35 min)	ASTM D-412	Kgf/cm3	MIN 150
Elongation (35 min)	ASTM D-412	%	MIN 440
300% Modulus at 145°C
25 min	ASTM D-412	Kgf/cm3	68-108
35 min			74-114
50 min			74-114
Rheometer at 160°C
MH	ASTM D-3189	Ibf in	32.0-40.0
ML		Ibf in	5.2-11.2
TS-1		MIN	2.1-6.1
T50		MIN	6.0-10.4
T90		MIN	8.3-13.1

Compound Recipe

Typical Properties	Test Method	Unit	Value
Raw BR-1220	ASTM D-3189	PART	100
HAF Carbon (IRB No.6)		PART	60
Zinc Oxide		PART	3
Stearic Acid		PART	2
Accelerator (TBBS)		PART	0.9
Sulfur		PART	1.5
Highly Aromatic Oil		PART	15
Vulcanization Temperature		°C	145

Other Specifications

Typical Properties	Test Method	Unit	Value
Anti Oxidant	Non Staining - High Quality
Catalyst Type	Cobalt
Packaging	35 Kg Bales, Wrapped in 50 Micron LDPE Film & Each 36 Bales are in a Box Pallet

*Certified Properties
**Values shown are averages & are not to be considered as product specifications.
